Features

• EN 60950-1, UL60950-1, IEC 60950-1, CSA C22.2 No. 60950-1-03, EN 60601-1, UL 60601-1, IEC 60601-1, CSA C22.2 No. 601-1, 2 x MOOP. 3. Traco 3W DIP Single/Dual Output Regulated Isolated DC-DC Converter - THI-3 Series. The THI-3 Series is a new family of High isolation 3W DC-DC converters, they have a reinforced insulation system, with I/O isolation voltage specified for 3000VACrms. These Tracopower converters come in an encapsulated DIP-24 package and are available in 15 models, covering 5, 12 and 24 VDC input voltage and single or dual output voltage. The THI-3 DC/DC converters are cost effective and they are an ideal solution for applications in industrial control and medical instrumentation which requires a certified supplementary or reinforced insulation system, making them suitable for medical safety or industrial standards. 3000VAC reinforced insulation 300VAC working voltage insulation rated Medical safety to UL/CSA/EN/IEC 60601-1 3rd edition and 2 x MOOP Fully regulated Output voltage Input filter meets EN 55022, class A and FCC, level A Operating temperature -40 to +75°C Low leakage current Low coupling capacitance Short circuit protection 3 year product warranty
