Features

• These board to board PCB solated power sockets mate with the IPT1 series shrouded PCB power terminals - see stock number ; 767-6862 767-6862 typically. Shrouded 2.54mm PCB Isolated Power Socket Strips - IPS1 Series. IPS1 series Mini Mate® board to board shrouded through hole PCB isolated power socket strips with a 2.54mm pitch and a height of 11.05mm when mated. These IPS1 series board to board PCB isolated power socket strips have a double row of 0.25μm gold plated Rugged™ individually shrouded Tiger Buy tuning fork style phosphor bronze contacts set inside a black glass LCP insulator. The temperature range at which these IPS1 series board-to-board shrouded PCB power sockets can be ***d is -55 to +125°C with a maximum power rating of 9A at an ambient temperature of 20°C. Part numbers IPS1-1XX-01-L-D are straight through hole mount Part numbers IPS1-1XX-01-L-D-RA are right angle through hole mount
