Features

• These TSW series PCB through hole board-to-board square post header terminals mate with the following: BCS standard box sockets - see stock number ; 766-6486 766-6486 typically CES low profile socket strips - see stock number ; 766-6600 766-6600 typically SLW low profile socket strips - see stock number ; 767-9408 767-9408 typically SSM surface mount socket strips - see stock number ; 765-5357 765-5357 typically SSQ socket strips - see stock number ; 765-5468 765-5468 typically SSW socket strips - see stock number ; 765-5593 765-5593 typically. Through Hole 2.54mm Square Post Header Terminal Strip - TSW Series. TSW series PCB through hole board-to-board square post header terminal strips with a 2.54mm pitch, a black, glass filled polyester insulator and phosphor bronze terminals with gold plated contacts. These PCB board to board through hole square post header terminal strips are available in a variety of configurations including single and double row, straight and right angle and an option of platings and post lengths. The operating temperature range for these TSW series PCB through hole header terminals is -55 to 125°C. TSW PCB headers with part number TSW-xxx-xx-x-S are single row. TSW PCB headers with part number TSW-xxx-xx-x-D are double row. TSW PCB headers with part number TSW-xxx-xx-L-x have 0.25μm gold on post and matte tin on tail. TSW PCB headers with part number TSW-xxx-xx-G-x have 0.25μm gold on post and gold flash on balance. TSW PCB headers with part number TSW-xxx-07-x-x have a terminal height of 5.84mm and a tail length of 2.54mm. TSW PCB headers with part number TSW-xxx-08-x-x have a terminal height of 5.84mm and a tail length of 5.08mm. TSW PCB headers with part number TSW-xxx-14-x-x have a terminal height of 8.13mm and a tail length of 2.79mm. TSW PCB headers with part number TSW-xxx-17-x-x have a terminal height of 15.74mm and a tail length of 2.79mm. TSW PCB headers with part number TSW-xxx-23-x-x have a terminal height of 5.84mm and a tail length of 2.92mm. TSW PCB headers with part number TSW-xxx-26-x-x have a terminal height of 5.84mm and a tail length of 3.20mm.
