Features

• Mates with SQT Series Sockets, see stock number ; 767-9568 767-9568 typical. Mates with SQW Series Sockets, see stock number ; 767-9650 767-9650 typical. Mates with TLE Series Sockets, see stock number ; 765-6079 765-6079 typical. Mates with SMM Series Sockets, see stock number ; 767-9470 767-9470 typical. Mates with MMS Series Sockets, see stock number ; 481-4796 481-4796 typical. TMM Series Low Profile SMT Pin Headers. These TMM Series of 2 mm pitch, Low Profile (2.77 mm), SMT Headers from Samtec have Gold Plated 3.2 mm long 0.5mm square posts.. Phosphor bronze, gold plated contacts Operating temperature: -55°C to +125°C with Gold Operating temperature: -55°C to +105°C with Tin Insulator Material: Black LCP. TMM-1xx-01-L-x-SM: 0.25μm Gold plated Posts with Tin Plated Tails TMM-1xx-01-G-x-SM: 0.75μm Gold plated Posts with 0.075μm Gold Plated Tails
