Electronic/Electrical Parts and Controll Equipments
64-0570-93 Cooper Bussmann 1F Supercapacitor EDLC -20 → +80% Tolerance Supercap B Series 2.5V dc Through Hole B0810-2R5105-R
model:
64-0570-93
brand:
Cooper Bussmann
Product Description
Product Model: 64-0570-93Product Brand: Cooper Bussmann […]
Contact Us
Product Details
Product Model: 64-0570-93
Product Brand: Cooper Bussmann
Features
- B series (PowerStor) Super Capacitors. Unique, ultra-high capacitance devices utilizing electrochemical double layer capacitor (EDLC) construction combined with new, high performance materials. Very low ESR for high power density Large capacitance for high energy density
Spec
- Quantity:1bag(100pieces)
- Capacitance:1F
- Voltage:2.5V dc
- Mounting Type:Through Hole
- Minimum Operating Temperature:-25°C
- Maximum Operating Temperature:+70°C
- Diameter:8.5mm
- Height:13.5mm
- Dimensions:8.5 (Dia.) x 13.5mm
- Lead Pitch:3.5mm
- Leakage Current:4 μA
- Equivalent Series Resistance:500mΩ
- Lifetime:1000h
- Series:Supercap B
- Tolerance:-20 → +80%
- Tolerance Plus:+80%
- CODE No.:161-7628
