64-0542-33 Electronic Assembly EA DOGL128L-6 Graphic LCD Display Yellow-Green, Reflective EA DOGL128L-6
model:
64-0542-33
brand:
Electronic Assembly
Product Description
Product Model: 64-0542-33Product Brand: Electronic Asse […]
Contact Us
Product Details
Product Model: 64-0542-33
Product Brand: Electronic Assembly
Features
- FSTN negative and STN negative display modules (displays with Black or Blue backgrounds) can only be ***d with a LED backlight fitted, such as stock no. ; 758-8737 758-8737. EA DOG Series of Monochrome Graphic Display Modules, Electronic Assembly. The EA DOG series of monochrome graphic display modules, from Electronic Assembly, was specially developed for low-power hand-held applications; allowing these display modules to be operated at 3.3V. Optional LED backlights (such as stock no. ; 758-8664 758-8664 ) can simply be clipped to the display modules to create different effects, see datasheet for details. An evaluation board ( 9780-2USB) is available for *** with DOG series display modules, see stock no. ; 758-8831 758-8831. Ultra thin high contrast LCD supertwist displays with 15μm dot gap Solders directly into the PCB without any further assembly required Single 3.3V power supply
Spec
- Quantity:1box(16pieces)
- Display Type:Graphic
- Character Rows:4, 8
- Resolution:128 x 64pixels
- Viewing Area Dimensions:64 x 35.5mm
- Interface Type:SPI
- External Depth:2.8mm
- Backlight Type:LED
- External Height:48mm
- Controller Type:ST 7565R
- Display Mode:Reflective
- Maximum Operating Temperature:+70°C
- Driver Mounting:PCB Mount
- CODE No.:171-1887
