Electronic/Electrical Parts and Controll Equipments
64-0538-26 Wurth WE-LHMI Series 22 μH ±20% Composite Iron Powder Multilayer SMD Inductor, 7050 Case, SRF: 8MHz 2.1A dc 170mΩ Rdc 74437349220
model:
64-0538-26
brand:
Wurth Elektronik
Product Description
Product Model: 64-0538-26Product Brand: Wurth Elektroni […]
Contact Us
Product Details
Product Model: 64-0538-26
Product Brand: Wurth Elektronik
Features
- WE-LHMI Series Magnetically Shielded Wirewound Chokes. WE-LHMI Series Magnetically shielded SMD power inductors with a high current capability. The compact WE-LHMI Series SMD power inductors are designed to handle high transient current spikes, with no acoustic noise and no leakage field. Applications for the WE-LHMI Series include: DC-DC converters for high current power supplies; DC-DC converters for field programmable gate arrays (FPGA); POL converters; Portable power (for example, PDA, digital camera); Mainboards / graphic cards; Battery powered devices devices
Spec
- Quantity:1piece
- Series:WE-LHMI
- Inductance:22 μH
- Tolerance:±20%
- Maximum DC Current:2.1A
- Maximum Self Resonant Frequency:8MHz
- Package/Case:7050
- Maximum DC Resistance:170mΩ
- Core Material:Composite Iron Powder
- Dimensions:6.6 x 6.6 x 4.8mm
- Depth:6.6mm
- Height:4.8mm
- Length:6.6mm
- Maximum Operating Temperature:+125°C
- Shielded:Yes
- CODE No.:756-8594
