64-0480-88 Nexperia, 3V Zener Diode 5% 550 mW SMT 2-Pin SOD-323F BZX84J-C3V0,115
Product Description
Product Model: 64-0480-88Product Brand: Nexperia Featur […]
Contact Us
Product Details
Product Model: 64-0480-88
Product Brand: Nexperia
Features
- Zener Diodes 550mW, BZX84J Series, Nexperia. The BZX84J series of Zener diodes, from NXP, are general purpose devices. These single Zener diodes are in a SOD323F (SC-90) package. This plastic package is very small and flat lead surface mount (SMD). The BZX84J series are ideal for general regulation functions.. - Non-repetitive peak reverse power dissipation: 40mW - Total power dissipation: 550mW - Small plastic package for suface-mount designs - Wide working voltage range: nominal 2.4V to 75V (E24 range) - Two tolerance series: 2% and 5% - Low differential resistance
Spec
- Quantity:1bag(100pieces)
- Diode Configuration:Single
- Number of Elements per Chip:1
- Maximum Power Dissipation:550 mW
- Package Type:SOD-323F
- Zener Type:Voltage Regulator
- Zener Voltage Tolerance:5%
- Pin Count:2
- Test Current:5mA
- Maximum Reverse Leakage Current:10µA
- Length:1.8mm
- Dimensions:1.8 x 1.35 x 0.8mm
- Typical Voltage Temperature Coefficient:-3.5 mV/°C, 0 mV/°C
- CODE No.:742-3964
