Features

• Hirose 2 mm DF59 Series Crimp Socket Housings. 2 mm DF59 Series wire to board crimp socket housings with a compact space saving design and a low profile mating height of 2.48 mm. These DF59 crimp housings *** a swing lock mechanism when mated which incorporates both positive and friction locks. A positive locking mechanism secures the housing to the header providing a tactile click when the lock is securely engaged. A complete electrical connection is then made by the friction lock mechanism which also produces a tactile click when fully engaged. This swing lock mechanism provides a secure connection and prevents accidental unmating ca***d by severe wiring and mechanical stress. The contacts for these DF59 series crimp housings must be purchased separately. Features and Benefits. Compact, space saving design Low profile mated height of 2.48 mm Swing lock mechanism incorporates positive and friction locks for secure connection High operating temperature of up to 105°C. Product Application Information. These 2 mm DF59 Series Multi-Functional Connectors are ideal for *** in LED lighting applications
