Features

• AEC-Q200 qualified. 35W 1% PWR263 Series ( TO263 package ). The PWR263S-35 SMD power resistor series from Bourns is rated to 35 W continuous power in a D 2 PAK package. The free to air power rating of the component is 2.8 W. Manufactured using thick film on alumina ceramic technology the PWR263S-35 SMD power resistor series is designed to withstand peak temperatures of 260°C during solder reflow. PWR263S-35 SMD power resistors are available in a wide resistance range. These resistors feature pulse power handling and low inductance. PWR263S-35 Power resistors are suited to current limiting, current sensing, capacitor discharge in battery charging, AC-DC, DC-DC and DC-AC conversion circuits. D 2 PAK housing Low inductance Resistor electrically isolated from the back plate High power rating Compatible with lead free solder reflow temperatures. Product Application Information. PWR263S-35 power resistors are AEC-Q200 qualified and suitable for automotive applications. Other ***s include uninterruptible power supplies, telecom power supplies, welding machines and automation. Suitable applications also include aerospace, lighting and railway equipment. Applications:-. Power supplies Motor drives Test and measurement Rectifiers
