Features

• UL 60950. MTBF to MIL-HDBK-217F The MER1 Series of converters are not internally f***d so to meet the requirements of UL 60950 an anti-surge input line f*** should always be ***d with ratings as defined below. MER1S05xxSC: 1A MER1S12xxSC: 0.375A MER1S15xxSC: 0.375A MER1S24xxSC: 0.2A MER1S48xxSC: 0.1A All f***s should be UL approved and rated to at least the maximum allowable DC input voltage. Murata 1W SIP Single Output Unregulated Isolated DC-DC Converter - MER1 Series. 1 W dual output SIP7 unregulated DC to DC converters with standard industry pinout and efficiency rating of up to 89%. These SIP7 DC to DC converters have an improved regulation performance making them suitable for applications where a wide output voltage variation can not be tolerated. An ideal application for these DC to DC converters is the provision of local supplies on control system boards with the additional benefit of having 1kVDC galvanic isolation to reduce any switching noise. SIP7 package with industry standard pinout Efficiency of up to 89% Wide temperature performance of -40 to + 85°C at full 1W load No heatsink or external components required Fully encapsulated with toroidal magnetics No electrolytic or tantalum capacitors UL94V-0 package material
