64-0408-19 Mean Well 450W 1 Output Embedded Switch Mode Power Supply SMPS, 90A, 5V dc Enclosed HRPG-450-5RS
Product Description
Product Model: 64-0408-19Product Brand: Mean Well Featu […]
Contact Us
Product Details
Product Model: 64-0408-19
Product Brand: Mean Well
Features
- UL60950-1, TUV EN60950-1. UL/cUL recognised, TUV, CB. Power derates above 50°C. MTBF to MIL-HDBK-217F. 5. HRPG-450 Series Single Output Power Supply with PFC Function. High efficiency, long life and high reliability No load power consumption ;0.5W Built-in active PFC function Built-in constant current limiting circuit Built-in cooling fan ON-OFF control Built-in DC OK signal Built-in remote sense function Built-in remote ON-OFF control Short circuit, over load, over voltage and over temperature protection Withstands 300Vac surge input for 5 seconds Power factor correction to EN61000-3-2,-3 EMC compliance to EN55022 class B
Spec
- Quantity:1piece/bag
- Output Voltage:5V dc
- Output Current:90A
- Power Rating:450W
- Number of Outputs:1
- Input Voltage:120 → 370 V dc, 85 → 264 V ac
- Mounting Type:Chassis Mount
- Package Type:Enclosed
- Length:218mm
- Width:105mm
- Depth:41mm
- Weight:1.2kg
- Efficiency:83%
- Maximum Temperature:+70°C
- Minimum Temperature:-40°C
- CODE No.:721-1705
Related product recommendations
You may also be interested in the following products
Electronic/Electrical Parts and Controll Equipments
63-6833-85 Insulation DC-DC Converter Vout: ± 3.3 V dc 9 to 36 V dc 3 W 24 V dc JTE0324D03
