Electronic/Electrical Parts and Controll Equipments
64-0408-16 Mean Well 201.6W 1 Output Embedded Switch Mode Power Supply SMPS, 8.4A, 24V dc Enclosed HRPG-200-24RS
Product Description
Product Model: 64-0408-16Product Brand: Mean Well Featu […]
Contact Us
Product Details
Product Model: 64-0408-16
Product Brand: Mean Well
Features
- UL60950-1, TUV EN60950-1. UL/cUL recognised, TUV, CB. Power derates above 40°C. MTBF to MIL-HDBK-217F. 5. HRPG-200 Series Single Output Power Supply with PFC Function. High efficiency, long life and high reliability No load power consumption ;0.5W Built-in active PFC function Built-in constant current limiting circuit Built-in remote sense function Built-in remote ON-OFF control Short circuit, over load, over voltage and over temperature protection Withstands 300Vac surge input for 5 seconds 1U low profile 38mm Power factor correction to EN61000-3-2,-3 EMC compliance to EN55022 class B
Spec
- Quantity:1piece/bag
- Output Voltage:24V dc
- Output Current:8.4A
- Power Rating:201.6W
- Number of Outputs:1
- Input Voltage:120 → 370 V dc, 85 → 264 V ac
- Mounting Type:Chassis Mount
- Package Type:Enclosed
- Length:199mm
- Width:98mm
- Depth:38mm
- Weight:770g
- Efficiency:88%
- Maximum Temperature:+70°C
- Minimum Temperature:-40°C
- CODE No.:721-1695
