64-0332-09 Schurter FMAC ECO Series 64A 480 V ac 60Hz Flange Mount RFI Filter, with Screw Terminals FMAC-091E-6410
Product Description
Product Model: 64-0332-09Product Brand: Schurter Featur […]
Contact Us
Product Details
Product Model: 64-0332-09
Product Brand: Schurter
Features
- VDE, UL. IEC 60939, UL 1283. FMAC Series. Schurter FMAC series single stage power line filter for 3-phase systems. The FMAC series is designed for *** in photovoltaic systems and industrial applications to offer protection against interference voltage form the mains supply. The FMAC series features high symmetrical and asymmetrical attenuation and a wide frequency range offer of 10kHz up to 300MHz. High attenuation Screw clamp terminals Voltage rating 480 and 520 V ac for worldwide acceptance Qualified for *** in equipment according IEC/EN 60950
Spec
- Quantity:1piece/bag
- Maximum Current Rating:64A
- Maximum Voltage Rating:480 V ac
- Mounting Type:Flange Mount
- Termination Style:Screw
- Number of Stages:Single Stage
- Operating Frequency:60Hz
- Length:141mm
- Depth:265mm
- Height:58mm
- Dimensions:141 x 265 x 58mm
- Minimum Operating Temperature:-25°C
- Maximum Operating Temperature:+100°C
- Resistance:1.4mΩ
- Power Loss:17W
- CODE No.:708-5689
