64-0322-28 TRACOPOWER TDR 3WI 3W Isolated DC-DC Converter Through Hole, Voltage in 4.5 → 18 V dc, Voltage out ±15V dc TDR 3-1223WI
Product Description
Product Model: 64-0322-28Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 64-0322-28
Product Brand: TRACOPOWER
Features
- Suitable common mode chokes: TDR 3-12xx : see stock number ; 745-1180 745-1180 TDR 3-24xx : see stock number ; 745-1200 745-1200 TDR 3-48xx : see stock number ; 745-1171 745-1171. 3. Traco 3W DIP Single/Dual Output Regulated Isolated DC-DC Converter - TDR 3WI Series. Compact design in DIP package Wide 4:1 input voltage range Fully regulated outputs No minimum load required I/O-isolation 1500 Vdc Operating temperature range –40 °C to +85 °C Short circuit protection Remote On/Off
Spec
- Quantity:1piece/bag
- Output Voltage:±15V dc
- Input Voltage Range:4.5 → 18 V dc
- Input Voltage Nominal:12 V dc
- Isolation Voltage:1500V dc
- Power Rating:3W
- Output Current:±100mA
- Mounting Type:Through Hole
- Number of Outputs:2
- Efficiency:81%
- Package:DIP 14
- Load Regulation:±1%
- Maximum Temperature:+85°C
- Depth:8.45mm
- CODE No.:706-5663
