64-0318-30 Recom REC3.5 3.5W Isolated DC-DC Converter Through Hole, Voltage in 18 → 36 V dc, Voltage out ±12V dc Medical REC3.5-2412DRW/R10/A
Product Description
Product Model: 64-0318-30Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 64-0318-30
Product Brand: Recom
Features
- IEC60601-1, CSA C22.2 601-1, CSA C22.2 No. 60950-1-03, UL 60601-1, UL 60950-1. CB, CSA. Operating temperature is without derating. MTBF to MIL-HDBK 217F (+25°C). Recom 3.5W DIP Single/Dual Output Medical Approved Regulated Isolated DC-DC Converter - REC3-R10/A Series. Regulated output 10kVdc reinforced isolation Industry standard DIP24 package Continuous short circuit protection Wide range input 2:1 Efficiency up to 86%
Spec
- Quantity:1piece/bag
- Output Voltage:±12V dc
- Input Voltage Range:18 → 36 V dc
- Input Voltage Nominal:24 V dc
- Isolation Voltage:10kV
- Power Rating:3.5W
- Output Current:±145mA
- Mounting Type:Through Hole
- Number of Outputs:2
- Medical Approved:Yes
- Package:DIP 24
- Load Regulation:±0.6%
- Maximum Temperature:+85°C
- Depth:10.2mm
- CODE No.:706-3825
