64-0301-45 EPCOS B84113H Series 10A 250 V ac/dc 50 → 60Hz Chassis Mount RFI Filter, with Tab Terminals, Single Phase B84113H0000B110
Product Description
Product Model: 64-0301-45Product Brand: EPCOS Features […]
Contact Us
Product Details
Product Model: 64-0301-45
Product Brand: EPCOS
Features
- ENEC10; UL; cUL. B84113H. Single phase B841113H series offer's low leakage current. It also has an easy to install compact design. It is ***d in many applications, such as switched mode power supplies for telecom/data systems. SIFI-H for very high insertion loss Terminals; (case B) up to 16A tab connectors 6.3 x 0.8 mm (case G) Threaded M5 studs for filters from 20A to 36A Polyurethane potting (UL 94 V−0)
Spec
- Quantity:1piece/bag
- Maximum Current Rating:10A
- Maximum Voltage Rating:250 V ac/dc
- Mounting Type:Chassis Mount
- Termination Style:Tab
- Number of Phases:1
- Series:B84113H
- Operating Frequency:50 → 60Hz
- Length:52mm
- Depth:117.5mm
- Height:43mm
- Dimensions:52 x 117.5 x 43mm
- Leakage Current:0.369 mA
- Maximum Operating Temperature:+100°C
- Standards Met:UL 1283
- CODE No.:702-4031
