64-0268-48 Huco Stainless Steel 41mm OD Bellows Coupling With Clamping Fastening 536.41.3535
Product Description
Product Model: 64-0268-48Product Brand: Huco Features S […]
Contact Us
Product Details
Product Model: 64-0268-48
Product Brand: Huco
Features
- Stainless Steel Bellows Couplings - Clamp Type. High torsional stiffness for positional accuracy Low inertia Ideal for servo drive applications with high precision dynamic position control Material: Aluminium hub; stainless steel bellows
Spec
- Quantity:1piece/bag
- Bore:12mm
- Outside Diameter:41mm
- Length:49.7mm
- Fastening Type:Clamping
- Torque Rating:5.66Nm
- Torsional Stiffness:2880Nm/rad
- Moment of Inertia:2390 x 10^-8kg/m²
- Misalignment - Angular:2.5°
- Misalignment - Parallel:0.15mm
- Misalignment - Axial:0.8mm
- Bellows Material:Stainless Steel
- CODE No.:693-2433
