Spec

• External dimensions (mm): 346 x 405 x 517
• Inner furnace dimensions (mm): 100 x 150 x 105
• Number of pieces: 1
• Temperature setting range: 100 ~ 1150 degrees C
• Temperature control system: PID control, Double R thermocouple
• Capacity: 1.5 L
• Maximum temperature reach time: approximately 60 minutes
• Operation function: Constant value operation/program operation (6 patterns 30 steps x 1, 15 steps x 2 patterns, 10 steps x 3 patterns)
• Safety devices: Self-diagnostic function (memory malfunction, sensor malfunction, heater disconnection, SSR short circuit, automatic overrise prevention function), overcurrent leakage breaker, overrise prevention device
• Exterior/Furnace: Chromium-free electrogalvanized steel sheet (chemical resistant baking coating)/Alumina fiber
• Power: 100 VAC 50/60 Hz 10 A (15 A)
• Weight: approximately 24 kg
• Accessory: Exhaust cap
• *Shipping, carrying-in, installation and assembly costs are required separately. Please inquire.
• Code: 214136
