Electronic/Electrical Parts and Controll Equipments
64-0227-61 Vishay 4700μF 100V dc Aluminium Electrolytic Capacitor, Chassis Mount 35 (Dia.) x 80mm +85°C 35mm MAL210119472E3
Product Description
Product Model: 64-0227-61Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 64-0227-61
Product Brand: Vishay
Features
- Screws and washers for termination are supplied. 101 PHR-ST Series. Vishay 101 PHR-ST series aluminium electrolytic capacitors have polarized screw terminals. The 101 PHR-ST series is suitable for a wide range of applications including buffering and filtering, motor drives, inverters, UPS, and pulsed power supplies. Long ***ful life Non-solid electrolyte High ripple current Insulated with a blue sleeve
Spec
- Quantity:1piece/bag
- Capacitance:4700µF
- Voltage:100V dc
- Mounting Type:Chassis Mount
- Technology:Electrolytic
- Dimensions:35 (Dia.) x 80mm
- Height:80mm
- Minimum Operating Temperature:-40°C
- Diameter:35mm
- Maximum Operating Temperature:+85°C
- Lifetime:10000h
- Series:101 PHR-ST
- Leakage Current:940 μA
- CODE No.:683-2014
