64-0200-31 Mean Well 500W Isolated DC-DC Converter Chassis Mount, Voltage in 19 → 72 V dc, Voltage out 48V dc SD-500L-48
Product Description
Product Model: 64-0200-31Product Brand: Mean Well Featu […]
Contact Us
Product Details
Product Model: 64-0200-31
Product Brand: Mean Well
Features
- IEC 60950-1. CB, TUV. De-rating above 50°C (stk no. ; 491-267 491-267 de-rates above 45°C). MTBF to MIL-HDBK-217F (25°C). 3. SD- 500 Series Single Output Enclosed Regulated Isolated DC-DC Converter. High reliability Ultra-wide 4:1 input voltage range Regulated outputs Easy installation - screw terminals Adjustable output voltage EMC meets EN 55022 Class B Forced air cooling by built-in fan Remote ON/OFF control Remote sense LED power-on indicator Short circuit, over-load, over-voltage and over-temperature protection 2kV input / output isolation
Spec
- Quantity:1piece/bag
- Output Voltage:48V dc
- Output Voltage Adjustment Range:46 → 60V
- Input Voltage Range:19 → 72 V dc
- Isolation Voltage:2kV ac
- Power Rating:500W
- Output Current:10.5A
- Mounting Type:Chassis Mount
- Number of Outputs:1
- Efficiency:89%
- Load Regulation:±0.5%
- Maximum Temperature:+60°C
- Depth:50mm
- CODE No.:678-3657
