Electronic/Electrical Parts and Controll Equipments
63-8434-62 Bourns SRN4012TA Series Wire-wound SMD Inductor with a Ferrite Core, 15 μH ±20% Semi-Shielded 750mA Idc Q:10 SRN4012TA-150M
Product Description
Product Model: 63-8434-62Product Brand: Bourns Features […]
Contact Us
Product Details
Product Model: 63-8434-62
Product Brand: Bourns
Features
- AEC-Q200. SRN4012 Series Semi Magnetically Shielded Power Inductors. Bourns SRN4012 series semi-shielded power inductors feature an inductance range of 0.47 to 22uH and a rated current up to3.2A, operating temperature of -40°C to +125°C. These inductors are suitable for the automotive industry and are AEC-Q200 qualified. Applications. Automotive systems: Driver assistant, information, lighting, entertainment DC-DC convertors Power supplies Televisions Smartphones HDDs
Spec
- Quantity:1set(4500pieces)
- Inductance:15 μH
- Maximum DC Current:750mA
- Length:4mm
- Automotive Standard:AEC-Q200
- Height:1.2mm
- Dimensions:4 x 4 x 1.2mm
- Tolerance:±20%
- Maximum DC Resistance:260mΩ
- Series:SRN4012TA
- Core Material:Ferrite
- Maximum Self Resonant Frequency:24MHz
- Inductor Construction:Semi-Shielded
- CODE No.:135-5278
