Features

• ANSI/AAMI ES 60601-1 2005(R) 2012 IEC/EN 60601-1 3rd edition. Traco 30W PCB Mount DC-DC Converters - THM 30WI Series. From TRACO POWER, a range of medically approved 30 W DC-DC converters. Supplied in a compact 2.0 x 1.0 package the THM-20WI series have a wide 4:1 voltage input range and input filter meeting EN55022 class A standards. The reinforced I/O isolation of these DC-DC converters complies with certification according to IEC/EN/ES 60601-1 3RD edition for 2 x MOPP (Means of Patient Protection).Efficient up to 89%, and the highest grade components the THM-30WI modules operate reliably within an ambient temperature range of -40°C to + 75°C. The robust DC-DC Converters are ideally suited to medical, transportation, control and measurement and IGBT drivers. Features and Benefits. Wide 4:1 input voltage 2.0 x 1.0 standard plastic case I/O isolation 5000 V ac RMS rated for 250 V ac RMS working voltage IEC/EN/ES 60601-1 3RD edition for 2xMOPP Input filter EN55022 class A Low leakage current Wide operating temperature range -40°C to + 75°C. Applications. Medical equipment Transportation Control and measurement IGBT drivers
