Features

• Traco Power THM 6 Series, 6 Watt. The THM-6 Series is a range of medical 6 W DC-DC converters in a DIP-24 plastic package with a wide 2:1 input voltage range. They provide a reinforced isolation system for 5000 V ac RMS isolation and a low leakage current of less than 2 μA. The units are approved to IEC/EN/ES 60601-1 3rd edition for 2 x MOPP (Means Of Patient Protection) and come with an ISO 14971 risk management file. Design and production conform to the quality management system ISO 13485, with a high efficiency of up to 89% and highest grade components. The converters can reliably operate in an ambient temperature range of –40°C up to +90°C. They constitute a reliable solution not only for medical equipment but also for demanding ranges of application such as transportation control and measurement or IGBT drivers. Features and Benefits. Wide 2:1 input voltage I/O isolation 5000 V ac RMS rated for 250 V ac RMS working voltage Certification according to IEC/EN/ES 60601-1 3rd edition for 2xMOPP Risk management process according to ISO 14971 including risk management file Acceptance criteria for electronic assemblies according to IPC-A-610 Level 3 Low leakage current Ext***ed operating temperature range –40°C to 90°C Input filter to meet EN55022 class A Operating up to 5000 m altitude 5-year product warranty A
