Features

• EN 55022 class A, FCC level A. Artesyn AYA Series DC/DC Converter. The AYA Series of 3 W Isolated DC-DC Converters Comprises 28 variants. Each of which is available in a mini dual-in-line package for through-hole mounting or a mini surface-mount package. They feature wide input voltage varying between 4.5 V to 10 V, 9 V to 18 V, 18 V to 36 V and 36 V to 75 V inputs. Offering up to 80% conversion efficiency, the converters *** 100 kHz fixed frequency switching to minimise the need for external EMI filtering. Typical applications for this range include data communication, telecommunication and computer peripheral, industrial automation and mobile battery powered systems. Features and Benefits. Ultra compact DIP Package 14 x 14 x 8.0 mm (0.55 x 0.55 x 0.31 in) Efficiency up to 87% I/O-isolation 1500 V dc Wide 2:1 Input Range Single and Dual output Operating Temperature Range -40 to +85 (for DIP module) Remote On/Off Continuous (hiccup mode) protection against output short circuits.
