Spec

• External Dimensions (mm): 370 x 300 x 400
• Can Body Dimensions (mm): φ230 x 220
• Can Capacity: 10 L
• Operating Temperature Range: 110~125°C (Setting/1°C Interval)
• Operating Pressure Range: 0~0.16 MPa
• Timer: 0~60min (Digital Temperature Control)
• Can Body, Lid, Surface Plate Material: Stainless Steel (SUS304), Bottom Packing: Silicone Rubber Molded Product
• Outer Plate Material: Steel Plate/Melamine Baked Coating
• Anti-Depletion Device: Heat Sensing Hydraulic Switch
• Pressure relief device: Cut-off method with pressure sensing sensor (Heater power off, alarm buzzer, red lamp lights)
• Safety Valve: Stainless Spring System Blow Pressure: 0.18 MPa
• Breaker: Overcurrent breaker (ground fault breaker: optional)
• Heater: 1.0 kW
• Power: 100 VAC 50/60Hz 10 A
• Weight: 16 kg
• Attached Stainless Steel Net Basket: Φ210 x 200 mm x 1
• Attached Exhaust Drain Receiving Tank: Poly Tank x 1
• *This product is not a medical device. Please use it for research and development purposes.
• *It cannot be used to sterilize medical instruments.
• Annex: Inspection and Inspection Documents
• *The product with inspection certificate is an original service of AZONE that checks the control and electric engine at the time of shipment and issues an inspection certificate.
• This product can be validated (IQ/OQ).　Please contact us.
• *Validation Service is a service where installation qualification (IQ) and operational performance qualification (OQ) are performed at the customer's site and inspection documents are submitted.
