Electronic/Electrical Parts and Controll Equipments
63-8363-71 XP Power IA 1W Isolated DC-DC Converter Through Hole, Voltage in 4.5 → 5.5 V dc, Voltage out ±24V dc IA0524S
Product Description
Product Model: 63-8363-71Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-8363-71
Product Brand: XP Power
Features
- XP Power - IA Series of Isolated DC-DC Converters. The IA series from XP Power offers a highly reliable range of dual output, 1 W, isolated DC-DC converters. The series features 1000 VDC in isolation and is available in both an industry standard SIP and DIP package. These dual output, DC-DC converters feature an industry standard pinout and have a wide -40 °C to +85 °C operating temperature. 1 W, isolated DC-DC converters 1000 VDC in isolation Dual output -40 °C to +85 °C Operating temperature Available in both a SIP and DIP package Up to 80% efficiency
Spec
- Quantity:1set(20pieces)
- Output Voltage:±24V dc
- Input Voltage Range:4.5 → 5.5 V dc
- Input Voltage Nominal:5 V dc
- Isolation Voltage:1kV dc
- Power Rating:1W
- Output Current:±21mA
- Mounting Type:Through Hole
- Number of Outputs:2
- Efficiency:80%
- Package:SIP
- Load Regulation:Maximum of 10%
- Maximum Temperature:+85°C
- Series:IA
- CODE No.:167-2160
