63-8359-45 Wurth Elektronik 3587, 3 Way Pluggable Terminal Block 691358710003
model:
63-8359-45
brand:
Wurth Elektronik
Product Description
Product Model: 63-8359-45Product Brand: Wurth Elektroni […]
Contact Us
Product Details
Product Model: 63-8359-45
Product Brand: Wurth Elektronik
Features
- Wurth WR-TBL 3587 Series 5.08mm Pitch IDC Terminal Block Plug Connectors. WR-TBL 3587 series terminal block plug connectors with a 5.08mm pitch and a horizontal wire entry.These 3587 series 5.08mm terminal block plugs feature stamped tin plated copper alloy IDC contacts for a secure connection to the conductor. The housings are made from green and orange UL94-V0 PA 66. These 5.08mm terminal block plugs will accept a wire size of 22-18 AWG (0.3 to 0.8 mm ;sup>2 ;/sup>)
Spec
- Quantity:1box(75pieces)
- Number of Contacts:3
- Pitch:5.08mm
- Number of Rows:1
- Mounting Type:Plug-In
- G***er:Female
- Termination Method:IDC
- Type:Plug
- Current Rating:7A
- Body Orientation:Horizontal
- Colour:Green, Orange
- Voltage Rating:300 V ac
- Series:3587
- Material:Nylon 66
- Width:14mm
- CODE No.:163-1764
