63-8346-05 Murata LQW18CN_00 Series Type 1608 Wire-wound SMD Inductor with a Ferrite Core, 100 nH ±10% Wire-Wound 1A Idc LQW18CNR10K00D
Product Description
Product Model: 63-8346-05Product Brand: Murata Features […]
Contact Us
Product Details
Product Model: 63-8346-05
Product Brand: Murata
Features
- LQW18CN Series SMD Chip Inductors. Murata LQW Series wire wound RF inductors incorporates a high Q value giving great attenuation characteristics inside the pass band of the filters. These LQW inductors are ***d in matching applications of antennas for maintaining the reception and transmission sensitivity of the antennas. The LQW has low Rdc characteristics and can be employed in choke circuits where high current levels flow. Features. There are two types of structure available for different applications High Q value Large currents can be supported Low DC resistance
Spec
- Quantity:1set(4000pieces)
- Inductance:100 nH
- Maximum DC Current:1A
- Package/Case:1608
- Length:1.6mm
- Depth:0.8mm
- Height:0.8mm
- Dimensions:1.6 x 0.8 x 0.8mm
- Tolerance:±10%
- Maximum DC Resistance:100mΩ
- Series:LQW18CN_00
- Core Material:Ferrite
- Moulded:Yes
- CODE No.:166-9879
