63-8314-28 STMicroelectronics L5991D, PWM Current Mode Controller, 1.5 A, 1000 kHz, 12 → 20 V, 16-Pin SOIC L5991D
model:
63-8314-28
brand:
STMicroelectronics
Product Description
Product Model: 63-8314-28Product Brand: STMicroelectron […]
Contact Us
Product Details
Product Model: 63-8314-28
Product Brand: STMicroelectronics
Features
- PWM Controllers, STMicroelectronics. Pulse-width modulator (PWM) controllers can support isolated and non-isolated AC-DC and DC-DC switch mode power supplies. They are based on the most popular topologies in both single-***ed, such as fly-back, forward or quasi-resonant controllers, and double-***ed configurations, such as asymmetrical half-bridge, for Switch Mode Power Supplies (SMPS). The PMW controllers also integrate a comprehensive set of protections for enhanced robustness and reliability.
Spec
- Quantity:1set(50pieces)
- Number of PWM Outputs:1
- Control Method:Current
- Topology:Boost, Flyback
- Rise Time:70ns
- Fall Time:35ns
- Maximum Switching Frequency:1000 kHz
- Mounting Type:Surface Mount
- Package Type:SOIC
- Pin Count:16
- Output Current:1.5 A
- Synchronous Pin:Yes
- Minimum Operating Temperature:-40 °C
- CODE No.:178-1412
