Electronic/Electrical Parts and Controll Equipments
63-8304-63 TSV992IST STMicroelectronics, High Speed, Op Amp, RRIO, 20MHz, 3 V, 5 V, 8-Pin MSOP TSV992IST
model:
63-8304-63
brand:
STMicroelectronics
Product Description
Product Model: 63-8304-63Product Brand: STMicroelectron […]
Contact Us
Product Details
Product Model: 63-8304-63
Product Brand: STMicroelectronics
Features
- TSV99x, TSV99xA, Rail-to-Rail I/O High Merit Factor Operational Amplifiers. The TSV991 (Single), TSV992 (Dual) and TSV994 (Quad) operational amplifiers feature an excellent speed/power consumption ratio. Low input offset voltage: 1.5 mV max. (A grade) Wide bandwidth 20 MHz Stable for gain ≥ 4 or ≤ -3 Low power consumption: 820 μA typical High output current: 35 mA Power supply operation from 2.5 V to 5.5 V Low input bias current, 1 pA ESD high tolerance: 5 kV
Spec
- Quantity:1set(4000pieces)
- Amplifier Type:High Speed
- Mounting Type:Surface Mount
- Package Type:MSOP
- Power Supply Type:Single
- Number of Channels per Chip:2
- Pin Count:8
- Typical Single Supply Voltage:3 V, 5 V
- Typical Gain Bandwidth Product:20MHz
- Typical Slew Rate:10V/µs
- Minimum Operating Temperature:-40 °C
- Typical Input Voltage Noise Density:21nV/√Hz
- CODE No.:168-5725
