Electronic/Electrical Parts and Controll Equipments
63-8303-52 TRACOPOWER TMR 2WI 2W Isolated DC-DC Converter Through Hole, Voltage in 36 → 75 V dc, Voltage out 3.3V dc TMR 2-4810WI
Product Description
Product Model: 63-8303-52Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 63-8303-52
Product Brand: TRACOPOWER
Features
- Operating temperature is without derating. 3. Traco 2W SIP Single/Dual Output Regulated Isolated DC-DC Converter - TMR 2WI Series. Ultra-wide 4:1 input voltage range SIP-9 Package Regulated outputs Excellent load and line regulation 1kV input / output isolation Built-in filter meets EN 55022, Class A and FCC,Level A Remote On/Off Control Continuous short circuit protection Non de-rating
Spec
- Quantity:1set(10pieces)
- Output Voltage:3.3V dc
- Input Voltage Range:36 → 75 V dc
- Input Voltage Nominal:48 V dc
- Isolation Voltage:1.5kV dc
- Power Rating:2W
- Output Current:500mA
- Mounting Type:Through Hole
- Number of Outputs:1
- Efficiency:70%
- Package:SIP 9
- Load Regulation:±1%
- Maximum Temperature:+85°C
- Series:TMR 2WI
- CODE No.:166-5439
Related product recommendations
You may also be interested in the following products
Electronic/Electrical Parts and Controll Equipments
63-8306-66 STMicroelectronics 200V 120A, Dual Silicon Junction Diode, 4-Pin ISOTOP STTH20002TV1 STTH20002TV1
