Features

• Vishay 1N5400-1N5408 General Purpose Plastic Rectifiers
• From Vishay, 1N5400-1N5408 are a range of general purpose rectifiers
• With a moulded epoxy body, this range of rectifiers have a DO-201AD package size
• Features and Benefits:
• Capable of managing high forward surges
• Low forward voltage drop
• Low leakage current
• Solder dip at +245 °C for a maximum of 10 seconds
• Flame retardant to UL94 V-O
• > 500 ns standard recovery
• Wide operating temperature range of -50 °C to +150 °C
• Matte tin plated leads, solderable per J-STD-002 and JESD 22-B102
• A coloured band indicates the cathode ***
• Product applications:
• 1N5400-1N5408 rectifiers are ideal for general purpose rectification in converters, inverters, freewheeling diodes and power supplies.
