Electronic/Electrical Parts and Controll Equipments
63-8180-49 RS PRO Uni-Directional 9.7mm Microphone Condenser -47dB 171-0882
Product Description
Product Model: 63-8180-49Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-8180-49
Product Brand: RS PRO
Features
- Electret Microphone Inserts. Range of SMT and PCB mounting miniature electret condenser microphone inserts
Spec
- Quantity:1set(100pieces)
- Sensitivity:-47dB
- Directivity:Uni-Directional
- Standard Operating Voltage:2V
- Output Impedance:2.2kΩ
- Signal to Noise Ratio:58dB
- Maximum Supply Current:0.5mA
- Dimensions:9.7 (Dia.) x 5mm
- Diameter:9.7mm
- Height:5mm
- Maximum Frequency:10kHz
- Maximum Operating Temperature:+70°C
- Minimum Frequency:100Hz
- Minimum Operating Temperature:-20°C
- CODE No.:171-0882
