Electronic/Electrical Parts and Controll Equipments
63-8179-35 Nichicon 100μF 25V dc Aluminium Electrolytic Capacitor, Surface Mount 6.3 (Dia.) x 8.7mm +105°C 6.3mm UCW1E101MCL1GS
Product Description
Product Model: 63-8179-35Product Brand: NICHICON Featur […]
Contact Us
Product Details
Product Model: 63-8179-35
Product Brand: NICHICON
Features
- CW Series Low Impedance. CW Series Aluminium Electrolytic Capacitors Chip type with load life of 7000 hours at +105°C Low impedance temperature range up to +105°C Applicable to automatic mounting machine fed with carrier tape
Spec
- Quantity:1set(800pieces)
- Capacitance:100µF
- Voltage:25V dc
- Mounting Type:Surface Mount
- Technology:Electrolytic
- Dimensions:6.3 (Dia.) x 8.7mm
- Height:8.7mm
- Minimum Operating Temperature:-25°C
- Diameter:6.3mm
- Maximum Operating Temperature:+105°C
- Lifetime:7000h
- Series:CW
- Leakage Current:3 μA
- CODE No.:171-0683
