63-8163-30 1294.1002 MENTOR, PCB Mounted LED Light Pipe, Clear Round Lens 1294.1002
Product Description
Product Model: 63-8163-30Product Brand: Mentor GmbH Fea […]
Contact Us
Product Details
Product Model: 63-8163-30
Product Brand: Mentor GmbH
Features
- Vertical Light Guides, 1 Row - Round (Switch). This family of vertical light guides, from MENTOR, consist of a single light pipe. The round heads are available in a 3 mm diameter and are parallel to the printed board on the front panel. This range are designed for *** with up to 3 Chipleds with an 0805 footprint or smaller. This enables the ***r to create bi-colour or tri-colour displays. Vertical light pipes are designed for *** with surface mount (SMD) LEDs and are fitted to the circuit board using push-fit lugs. The light pipe inject face sits in close proximity to the LED on the board.. Features of the vertical light guides: For *** with 3 LEDs Round heads PC clear UL94 Ambient temperature: -40°C to +85°C
Spec
- Quantity:1bag(100pieces)
- Flexible/Rigid:Rigid
- Length:30mm
- Dimensions:30 x 13 x 3mm
- Mounting Type:PCB Mounted
- Lens Shape:Round
- Number of Ways:1
- Rows:1
- LED Included:No
- Lens Colour:Clear
- Outer Diameter:3mm
- CODE No.:170-7696
