63-8146-40 Semtech SR2.8.TCT, Uni-Directional TVS Diode Array, 200W, 4-Pin SOT-143 SR2.8.TCT
Product Description
Product Model: 63-8146-40Product Brand: Semtech Feature […]
Contact Us
Product Details
Product Model: 63-8146-40
Product Brand: Semtech
Features
- RailClamp®, Low Capacitance TVS Diode Array, SR Series. 500 Watts Peak Pulse Power (tp:8/20μs) ESD protection to: IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact) IEC 61000-4-4 (EFT) 40A (5/50ns) IEC 61000-4-5 (Lightning) 24A (8/20μs) Array of surge rated diodes with internal TVS Diode Protects two I/O lines Low capacitance ( ;10pF) for high-speed interfaces
Spec
- Quantity:1set(3000pieces)
- Direction Type:Uni-Directional
- Maximum Clamping Voltage:8.5V
- Minimum Breakdown Voltage:2.8V
- Mounting Type:Surface Mount
- Package Type:SOT-143
- Maximum Reverse Stand-off Voltage:2.8V
- Pin Count:4
- Peak Pulse Power Dissipation:200W
- Maximum Peak Pulse Current:14A
- ESD Protection:Yes
- Number of Elements per Chip:1
- Minimum Operating Temperature:-55 °C
- Maximum Operating Temperature:+125 °C
- Height:1.1mm
- CODE No.:170-0845
