63-8120-78 Littelf*** SZP6SMB20AT3G, Uni-Directional TVS Diode, 600W, 2-Pin DO-214AA SZP6SMB20AT3G
Product Description
Product Model: 63-8120-78Product Brand: Littelfuse Feat […]
Contact Us
Product Details
Product Model: 63-8120-78
Product Brand: Littelfuse
Features
- 600W Zener SMT Transient Voltage Suppressors, P6SMB Series (Unidirectional)
Spec
- Quantity:1bag(10pieces)
- Diode Configuration:Single
- Maximum Clamping Voltage:27.7V
- Minimum Breakdown Voltage:19V
- Mounting Type:Surface Mount
- Package Type:DO-214AA (SMB)
- Maximum Reverse Stand-off Voltage:17V
- Pin Count:2
- Peak Pulse Power Dissipation:600W
- Maximum Peak Pulse Current:22A
- ESD Protection:Yes
- Number of Elements per Chip:1
- Minimum Operating Temperature:-65 °C
- Maximum Operating Temperature:+150 °C
- Test Current:1mA
- CODE No.:786-4687
