63-8103-24 ON Semiconductor SMCJ15A, Uni-Directional TVS Diode, 1500W, 2-Pin DO-214AB SMCJ15A
model:
63-8103-24
brand:
ON Semiconductor
Product Description
Product Model: 63-8103-24Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-8103-24
Product Brand: ON Semiconductor
Features
- Transient Voltage Suppressors SMT Unidirectional 1500W, SMCJ Series, Fairchild Semiconductor. Glass-Passivated Junction 1500W Peak Pulse Power Capability Excellent Clamping Capability Low-Incremental Surge Resistance Fast Response Time UL Certificate #E258596 UL94V-0 Flammability Classification
Spec
- Quantity:1bag(20pieces)
- Diode Configuration:Single
- Maximum Clamping Voltage:24.4V
- Minimum Breakdown Voltage:16.7V
- Mounting Type:Surface Mount
- Package Type:DO-214AB (SMC)
- Maximum Reverse Stand-off Voltage:15V
- Pin Count:2
- Peak Pulse Power Dissipation:1500W
- Maximum Peak Pulse Current:61.5A
- Number of Elements per Chip:1
- Maximum Operating Temperature:+150 °C
- Width:6.25mm
- CODE No.:802-2449
