63-8097-24 LM358PT STMicroelectronics, Low Power, Op Amp, 1.1MHz, 5 → 28 V, 8-Pin TSSOP LM358PT
model:
63-8097-24
brand:
STMicroelectronics
Product Description
Product Model: 63-8097-24Product Brand: STMicroelectron […]
Contact Us
Product Details
Product Model: 63-8097-24
Product Brand: STMicroelectronics
Features
- LM158, LM258, LM358, Low Power Dual Operational Amplifiers with Low Input Bias Current. The LM158, LM258, LM358 operational amplifiers consist of two indep***ent, high-gain, internally frequency-compensated circuits. In linear mode, the input common-mode voltage range includes ground and the output voltage can also swing to ground. Designed to operate from a single power supply Large DC voltage gain: 100 dB Wide bandwidth (unity gain): 1.1 MHz
Spec
- Quantity:1bag(25pieces)
- Amplifier Type:Low Power
- Mounting Type:Surface Mount
- Package Type:TSSOP
- Power Supply Type:Dual, Single
- Number of Channels per Chip:2
- Pin Count:8
- Typical Single Supply Voltage:5 → 28 V
- Typical Gain Bandwidth Product:1.1MHz
- Typical Dual Supply Voltage:±12 V, ±3 V, ±5 V, ±9 V
- Typical Slew Rate:0.6V/µs
- Minimum Operating Temperature:0 °C
- Dimensions:3 x 4.4 x 1mm
- CODE No.:714-7412
