Features

• dsPIC30F1010/202x 16-Bit Digital Signal Controllers. Microchip s dsPIC30F family of Digital Signal Controllers (DSCs) offer designers DSP like performance with the simplicity of an MCU. The dsPIC30F1010/202x range of devices feature peripherals to support digital switch-mode power supplies (SMPS) and other digital power conversion applications. CPU Features. 30 MIPS Max. CPU Speed Modified Harvard architecture C Compiler optimized instruction set architecture 83 base instructions with flexible addressing modes 24-bit wide instructions, 16-bit wide data path 12 Kbytes on-chip Flash program space 512 bytes on-chip data RAM 16 x 16-bit working register array 32 interrupt sources Three external interrupt sources 8 ***r-selectable priority levels for each interrupt 4 processor exceptions and software traps. DSP Engine Features. Modulo and Bit-Reversed modes Two 40-bit wide accumulators with optional saturation logic 17-bit x 17-bit single-cycle hardware fractional/integer multiplier Single-cycle Multiply-Accumulate (MAC) operation 40-stage Barrel Shifter Dual data fetch. Peripheral Features. High-current sink/source I/O pins: 25 mA/25 mA Three 16-bit timers/counters – option to pair up 16-bit timers into 32-bit timer modules One 16-bit Capture input functions Two 16-bit Compare/PWM output functions Four PWM generators with 8 outputs 10-Bit 2000 Ksps Analogue-to-Digital Converter (ADC) – 6 to 12 channels dep***ing on model Four Analogue Comparators 3-wire SPI modules I2CTM module UART Module
