63-8058-84 Wurth WE-KI Series Type 1008A Shielded Wire-wound SMD Inductor with a Ceramic Core, 39 nH Wire-Wound 1A Idc Q:60 744762139A
model:
63-8058-84
brand:
Wurth Elektronik
Product Description
Product Model: 63-8058-84Product Brand: Wurth Elektroni […]
Contact Us
Product Details
Product Model: 63-8058-84
Product Brand: Wurth Elektronik
Features
- Wurth 1008 WE-KI Series Wire-Wound Inductors. Wurth WE-KI Series 1008 SMD wire-wound ceramic inductors have been designed for high frequency applications. They offer the highest possible self resonant frequencies up to 12.5 GHz alongside an excellent Q factor and high thermal stability. Other applications for these ceramic inductors include wireless LAN, Bluetooth and RF transceiver/communications. Reflow soldering is recomm***ed for these products.
Spec
- Quantity:1set(2000pieces)
- Inductance:39 nH
- Maximum DC Current:1A
- Package/Case:1008A
- Length:2.5mm
- Depth:2mm
- Height:1.6mm
- Dimensions:2.5 x 2 x 1.6mm
- Shielded:Yes
- Maximum DC Resistance:100mΩ
- Series:WE-KI
- Core Material:Ceramic
- Maximum Self Resonant Frequency:1.5GHz
- Minimum Operating Temperature:-40°C
- CODE No.:163-7481
