63-8056-97 EPCOS 470 μH ±5% Ferrite Leaded Inductor, Max SRF:1.8MHz, Q:30, 510mA Idc, 1.9Ω Rdc HLBC B82145A1474J000
Product Description
Product Model: 63-8056-97Product Brand: EPCOS Features […]
Contact Us
Product Details
Product Model: 63-8056-97
Product Brand: EPCOS
Features
- Epcose B82145A HLCB Series RF Chokes. Epcos B82145A HLBC series RF chokes are suitable for application in interference suppression, decuopling, energy saving lamps and entertainment electronics. These high current large bobbin core inductors consist of a large ferrite drum core with enamel copper wire winding and a flame retardant lacquer coating. Suitable for wave soldering High rated current at high inductance ratings Terminals are radially bent to 5mm lead spacing Terminals are electroplated with nickel and pure tin
Spec
- Quantity:1bag(10pieces)
- Inductance:470 μH
- Maximum DC Current:510mA
- Mounting Type:Axial
- Maximum DC Resistance:1.9Ω
- Tolerance:±5%
- Diameter:6.5mm
- Length:12mm
- Dimensions:6.5 (Dia.) x 12mm
- Core Material:Ferrite
- Maximum Self Resonant Frequency:1.8MHz
- Lead Pitch:15mm
- Series:HLBC
- Terminal Type:Axial Leaded
- CODE No.:880-7278
