Features

• Compliance with DIN 46228, 1 and 4. Weidmuller PZ 10 Bootlace Ferrule Hex Crimp Tool. PZ 10 hex radial crimping tool for crimping wire *** ferrules with or without plastic collars with a wire size range of 0.14 to 10mm ;sup>2 ;/sup>. With such a wide wire range in one tool the need to change tools is eliminated along with associated crimping errors. This PZ 10 hex crimp hand tool produces hexagonal crimps with a small diameter rounded crimp form making it ideal for confined clamping spaces. Hexagonal wire *** ferrules provide a more secure connection than other crimping forms for screw, spring or direct-plug in clamping systems. Two crimping surfaces are always positioned in parallel to one another providing enough space to create a stable connection including direct plug-in connections. This PZ 10 crimp tool features a ratchet system which keeps the tool closed until the crimp is complete ensuring a consistent crimping quality. A release option is also incorporated in case of incorrect operation. The handles have an ergonomic design and do not spring open after crimping making the PZ 10 hand crimp tool safe and comfortable to ***. Features and Benefits: Wide crimping range of 0.14 to 10mm ;sup>2 ;/sup> eliminates the need to change tools Meets DIN and UL standards for large cross-sections measuring from 0.14 mm² to 10 mm². Round shaped crimp shape with small diameter ideal for limited clamping space Ratchet mechanism guarantees consistent crimp quality Release option in the event of incorrect operation Ergonomically designed handles Typical Applications: Maintenance ; repair Electrical Installations Cable assemblies FAQ ‘s: What is the difference between un-insulated and insulated crimp tools? Un-insulated crimp tools are typically ***d for general applications, whereas the insulated crimp tools have been VDE tested up to 1000 V, designed for *** where electrical current is present. How do you maintain the product? Axles and other movable parts should be regularly lubricated. Lubrication* is recomm***ed at least every 10,000 cycles whenever the tool is exposed to contaminants. Adjustment of the crimping die nests should also be checked. Readjustment of the pressure adjustment axle is necessary when the pre-load of the tool decreases significantly. The Importance of a High-Quality Crimp When a crimping tool is ***d on a terminal, two crimps take place at the same time. One is the electrical connection between the conductor and terminal. The other is the insulation crimp which provides strain relief against vibration and tension. It is important that the electrical connection is gas-tight without any voids between the wire strands and the terminal. If there any voids present, then corrosion can occur causing resistance and excessive heat which damages the electrical connection. Using a good quality crimping tool will ensure that a full, gas-tight crimp is produced preventing future deterioration of the electrical connection and insulation breakage.
