63-8040-01 Recom 4W 1 Output Embedded Switch Mode Power Supply SMPS, 333mA, 12V dc Encapsulated RAC04-12SC/W
Electronic/Electrical Parts and Controll Equipments

63-8040-01 Recom 4W 1 Output Embedded Switch Mode Power Supply SMPS, 333mA, 12V dc Encapsulated RAC04-12SC/W

model: 63-8040-01
brand: Recom

Product Description

Product Model: 63-8040-01Product Brand: Recom Features […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-8040-01
Product Brand: Recom

Features

  • EN-60950-1, IEC-60950-1, UL-60950-1. EN, UL and CE. 3. Recom 4W, Encapsulated, Switch Mode AC-DC Power Supply - RAC04-SC/W Series. The Recom RAC04-C/W is a series of 4W, single output encapsulated Power Supplies. This Regulated AC/DC converter comes with an integrated input filter and enhanced EMI performance which complies with EN55022, class B. This AC/DC Converter has very low Standby Power consumption of 100mW typical, which makes it particularly suitable for energy-saving sleep mode and stand-by applications. The compact design of the RAC04-C/W makes it a versatile solution for home automation and other similar applications The Recom RAC04-C/W comes with a three year warranty. Universal input 80-264Vac or 115-370Vdc Operating temperature range -25°C to +85°C Isolated output 3kVac / 1 minute Short circuit and overcurrent protection Low output ripple and noise Low cost AC-DC power supply

Spec

  • Quantity:1piece
  • Output Voltage:12V dc
  • Output Current:333mA
  • Power Rating:4W
  • Number of Outputs:1
  • Mounting Type:Through Hole
  • Package Type:Encapsulated
  • Length:37.8mm
  • Width:23.9mm
  • Depth:15.65mm
  • Weight:32g
  • Efficiency:77%
  • Maximum Temperature:+60°C
  • Minimum Temperature:-20°C
  • CODE No.:843-2008
