Features

• 2 x MOPP Medical safety according to AAMI/ANSI ES 60601-1:2005(R) and IEC/EN 60601-1 3rd edition. 3. 40W Medical Switch Mode Power Supply TPP Series. The Traco Power TPP 40 series of AC-DC power supplies feature 4000Vac I/O isolation system, according to the latest medical safety standards. This Power supply has an excellent efficiency up to 92% which allows high power density for the standard packaging format. The full load operating temperature range of this AC-DC power supply is -40°C to +73°C with 80% load derating. The TPP 40 series of power supplies comes with built-in class B filter. The power supplies are ready to meet ErP directive, with ˂0.3W no load power consumption. Ideal applications of the TPP 40 series of Power supplies are in applications for demanding safety and space critical ***s and with medical devices. Highest power density encased 40W power supply Wide input range 85-264Vac Highest efficiency 91 to 92% across 10% – 100% load range Active power factor correction (>95) Protection class I and II Low leakage current
