63-8039-22 Joystick Controller, 2 axes, 10 (Short Time Wiper Current) mA Teflon Wire (4Wire), -40 → +105°C 842-7172
Product Description
Product Model: 63-8039-22Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-8039-22
Product Brand: RS PRO
Features
- RS Pro Two Axis Joystick Controllers. RS Pro Joystick Controllers which are constructed from a conductive plastic that is optimised for a long life and an anodised aluminium precision machined body. These two axis joystick controllers offer a noise free output due to the *** of a precious metal wiper. With a resistance range of 5 kΩ, these joystick controllers also have an infinite resolution. Features and Benefits:. 1 W power rating at 70°C Nitrial rubber boot Stainless steel mounting flange ±20% standard resistance tolerance ; 842-7175 842-7175 has a push button, ; 842-7172 842-7172 does NOT have a push button
Spec
- Quantity:1piece
- Number of Axes:2
- Switch Technology:Dual Axis Potentiometric
- Handle Type:Knob
- Contact Current Rating:10 (Short Time Wiper Current) mA
- Joystick Travel:25-0-25 °
- Terminal Type:Teflon Wire (4Wire)
- Mechanical Life:2000000Operations
- Depth Behind Panel:40mm
- Minimum Operating Temperature:-40°C
- Maximum Operating Temperature:+105°C
- Operating Temperature Range:-40 → +105°C
- CODE No.:842-7172
