63-8039-18 Joystick Controller, 1 axes, 10 (Short Time Wiper Current) mA Teflon Wire (4Wire), -45 → +105°C 173-0770
Product Description
Product Model: 63-8039-18Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-8039-18
Product Brand: RS PRO
Features
- RS Single Axis Joystick Controllers. Constructed from a conductive plastic that is optimised for a long life and an anodised aluminium precision machined body, these single axis joystick controllers offer a noise free output due to the *** of a precious metal wiper. With a resistance range of 5kΩ, these joystick controllers have an essentially infinite resolution. 1W power rating at 70°C Nitrial rubber boot Stainless steel mounting flange ±20% standard resistance tolerance
Spec
- Quantity:1box(5pieces)
- Number of Axes:1
- Switch Technology:Single Axis Potentiometric
- Handle Type:Knob
- Contact Current Rating:10 (Short Time Wiper Current) mA
- Joystick Travel:25-0-25 °
- Terminal Type:Teflon Wire (4Wire)
- Mechanical Life:2000000Operations
- Depth Behind Panel:40mm
- Minimum Operating Temperature:-45°C
- Maximum Operating Temperature:+105°C
- Operating Temperature Range:-45 → +105°C
- CODE No.:173-0770
