63-8033-22 Alpha Wire 10 Core Foil Industrial Cable, 0.35 mm²(CE, CSA, UL) Grey 30m Reel, Alpha Essentials Series 1299/10C SL005
Product Description
Product Model: 63-8033-22Product Brand: Alpha Wire Feat […]
Contact Us
Product Details
Product Model: 63-8033-22
Product Brand: Alpha Wire
Features
- ULAWM 2576 (150 V), VW-1, UL CM, CSA FT4
- 300 V Foil Shield Multi-Conductor Cable
- Foil Shield Multi-Conductor Cable can be ***d in environments with moderate EMI levels.
- Provides excellent high-frequency shielding.
- Features and Benefits; Stranded tin-plated copper conductor; Aluminum/polyester foil shield for added strength and insulation; PVC insulation; Overall flame-resistant PVC jacket
Spec
- Quantity:1set
- Number of Cores:10
- Cross Sectional Area:0.35 mm²
- Screened/Unscreened:Screened
- Length:30m
- Sheath Colour:Grey
- American Wire Gauge:22 AWG
- Outer Diameter:6.81mm
- Screen Type:Foil
- Maximum Operating Temperature:+80°C
- Core Strands:7/0.25 mm
- Sheath Material:Polyvinyl Chloride PVC
- Voltage Rating:300 V
- Conductor Resistance:16.4 Ω/1000ft
- CODE No.:828-2477
