Electronic/Electrical Parts and Controll Equipments
63-8023-14 Recom 4W Dual Output Embedded Switch Mode Power Supply SMPS, 166mA, ±12V dc Encapsulated RAC04-12DC/230
Product Description
Product Model: 63-8023-14Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 63-8023-14
Product Brand: Recom
Features
- EN-60950-1, UL-60950-1. EN, UL and CE certified. 3. Recom 4W, PCB Mount, Encapsulated, Switch Mode AC-DC Power Supply - RAC04-C/230 Series. The RAC04-C/230 Power Supply comes in an encapsulated PCB-mount package style. This 4W Regulated AC/DC converter offers universal input and High efficiency of up to 79%. The RAC04-C/230 has a Maximum No Load ˂100mW with a 3.75kVac isolation. Ideal applications of this encapsulated power supply are in home automation, board-level power supplies, instrumentation systems and standby applications. The Recom RAC04/277 regulated converter comes with a three year warranty. Universal input 80-26Vac High efficiency up to 79% Isolated Output 3.75kVac / 1 minute Short circuit protection Meets EN55022 Class B
Spec
- Quantity:1piece
- Output Voltage:±12V dc
- Output Current:166mA
- Power Rating:4W
- Number of Outputs:2
- Input Voltage:80 → 264V ac
- Mounting Type:Through Hole
- Package Type:Encapsulated
- Length:36.7mm
- Width:27.2mm
- Depth:17.1mm
- Efficiency:78%
- Maximum Temperature:+65°C
- Minimum Temperature:-40°C
- CODE No.:817-9826
